JLT1014P 10″ rugged vehicle-mount computer

  • Future proof – runs Windows 11 or Windows 10
  • 10.4” standard or sunlight-readable display
  • Intel® x6413E processor
  • IP65 waterproof and dustproof
  • Virtually unbreakable JLT PowerTouch™ display
  • Dual-diversity PIFA WLAN antennas
  • Smallest footprint on the market, ideal for use in tight spaces
  • Optional integrated mobile broadband modem
  • Wi-Fi 6E
  • Future proof – runs Windows 11 or Windows 10
  • 10.4” standard or sunlight-readable display
  • Intel® x6413E processor
  • IP65 waterproof and dustproof
  • Virtually unbreakable JLT PowerTouch™ display
  • Dual-diversity PIFA WLAN antennas
  • Smallest footprint on the market, ideal for use in tight spaces
  • Optional integrated mobile broadband modem
  • Wi-Fi 6E

Reliable workhorse for the logistics industry

The JLT1014P gives you the main features of the JLT1214P – one of the most reliable workhorses for the logistics industry – but in the industry’s most compact form factor, making it the perfect choice for installation in tight spaces.

Ideal for forklifts or other logistics vehicles

The JLT1014P is designed from the ground up for the challenges of logistics applications. It packs the latest technology for maximum reliability and trouble-free operation in tough environments. Combining true ruggedness with outstanding convenience, it’s ideal for forklifts or other logistics vehicles.

Ensuring reliable wireless communication

Featuring an Intel® x6413E processor and an optional sunlight-readable XGA display, the JLT1014P computer is ready for anything. High-sensitivity PIFA antennas for Wi-Fi and Bluetooth ensure reliable wireless communication over long distances in challenging environments.

Product Highlight

The industry’s smallest form factor

JLT1014P is the perfect choice for installation in tight spaces

Outstanding value for warehousing logistics

Smart design makes the JLT1014P a cost-effective option

Maximized uptime with JLT:Care

Complete peace of mind with JLT:Care™, the no-questions-asked service agreement from JLT

Product Specifications

Base Unit

Processor:

Intel® x6413E

Memory:

8GB DDR4 (max 32GB)

Display:

10.4” XGA LED 400NIT
10.4” XGA LED 800NIT

Capacitive touch screen with JLT PowerTouch™ technology and hardened glass

Storage

SATA:

CFast 60GB, 120GB, 240GB

RF Options

Radio:

Dual-band WLAN 802.11ax, 802.11a/b/g/n/ac,
MU-MIMO supported
Bluetooth v5.2
4G (LTE) up to 150 Mbps download speed (optional)

GPS:

A-GPS/GLONASS/BEIDOU (optional)

Antennas:

WLAN dual-diversity antennas (PIFA)
External SMA connectors for 4G and GPS Optional external WLAN and Bluetooth antennas

Interfaces

Ports:

4x USB 2.0
1x Ethernet 10/100/1000
1x RS232 with 5V supply

Speakers:

Waterproof stereo speakers

HD audio

Buttons:

Power
LED dimming +/-

Security

TPM module

Power Supply

Input:

9-36 VDC unisolated

UPS:

Internal battery to avoid sudden shutdown at unexpected power outages

Operating Systems

Windows:

Windows 11 IoT Enterprise LTSC
Windows 10 IoT LTSC

Physical Characteristics

Dimensions:

251 mm (w) x 218 mm (h) x 46 mm (d)
9.88 inches (w) x 8.58 inches (h) x 1.81 inches (d)

Weight:

2.2kg, 4.0 lb.

Environment

Operating temp.:

-30° C to 55° C / -22° F to 131° F

Storage temp.:

-35° C to 75° C / -31° F to 167° F

Humidity:

10–95% RH

Dust and water:

IP65 – IEC 60529:2001

Vibration:

5–500 Hz/0,04 m/s2 XYZ – IEC 60068-2-64 Fh

Shock:

30 g for 11 ms XYZ – IEC 60068-2-27

MIL-SPEC:

810G in applicable areas

Base Unit

Processor:

Intel® x6413E

Memory:

8GB DDR4 (max 32GB)

Display:

10.4” XGA LED 400NIT
10.4” XGA LED 800NIT

Capacitive touch screen with JLT PowerTouch™ technology and hardened glass

Interfaces

Ports:

4x USB 2.0
1x Ethernet 10/100/1000
1x RS232 with 5V supply

Speakers:

Waterproof stereo speakers

HD audio

Buttons:

Power
LED dimming +/-

Storage

SATA:

CFast 60GB, 120GB, 240GB

Power Supply

Input:

9-36 VDC unisolated

UPS:

Internal battery to avoid sudden shutdown at unexpected power outages

Physical Characteristics

Dimensions:

251 mm (w) x 218 mm (h) x 46 mm (d)
9.88 inches (w) x 8.58 inches (h) x 1.81 inches (d)

Weight:

2.2kg, 4.0 lb.

RF Options

Radio:

Dual-band WLAN 802.11ax, 802.11a/b/g/n/ac,
MU-MIMO supported
Bluetooth v5.2
4G (LTE) up to 150 Mbps download speed (optional)

GPS:

A-GPS/GLONASS/BEIDOU (optional)

Antennas:

WLAN dual-diversity antennas (PIFA)
External SMA connectors for 4G and GPS Optional external WLAN and Bluetooth antennas

Security

TPM module

Operating Systems

Windows:

Windows 11 IoT Enterprise LTSC
Windows 10 IoT LTSC

Downloads

PDF

Data sheet JLT1014P

Download Data Sheet
PDF

Data Sheet JLT:Care EMEA

Download Data Sheet
PDF

JLT:Care service agreement (Americas)

Download Data Sheet

Data sheet JLT1014P

Data Sheet JLT:Care EMEA

JLT:Care service agreement (Americas)
